DIY Full Band Radio V5A FM AM MW SW Aviation Band SSB LSB USB Kit Not Assembled
Feature Manual Click here to openNote 1 Please read the instructions carefully After assembly you need to install the battery The type c port is only used for charging and flashing not power 2 Do not connect the battery in reverse as this may burn out the motherboard Warranty will be void if the motherboard is burned out due to reverse connection of the battery How to turn on the machine 1 Unplug the charging cable after installing the battery 2 Turn on the power in the middle and press and hold the encoder for 3 seconds Welcome to Full Band Radio V5A Edition This product includes two modes of digital analog output The digital output is driven by a Class D power amplifier and the analog output is driven by an analog operational amplifier In different modes this product supports different functions Analog output mode Analog output mode supports frequency modulation FM amplitude modulation AMM medium wave MW short wave SW aviation band single sideband SSB LSB lower sideband USB upper sideband Full band radio FM 64Mhz 108MHz AM medium wave MW 520KHz 1710KHz AM shortwave SW 3 5MHz 30MHz AM Single Sideband SSB 3 5MHz 30MHz BFO adjustment 0 2000Hz Aviation band 118MHz 137MHz UHF expansion Not includes supports UHF band reception transmission function through expansion board please comply with local laws and regulations Package includes Set 1 1 x Finished product kitPacking weight 235gPackaging size 11 5×11 5×3 5cmPackaging plastic
